15 Inch Industrial Panel PC

IP65 Front | 1024×768, 500 cd/m² | Intel i3-3217U | 10-Point Capacitive Touch

15″ LED display, 1024×768 resolution, 500 cd/m² brightness for clear visibility.
IP65 front with 3mm tempered glass and aluminium housing for harsh environments.
10-point projected capacitive touch, fast 20/10 ms response.
Intel i3-3217U dual-core 1.8GHz, 4GB DDR3 RAM, 128GB mSATA SSD.
Rich I/O: HDMI OUT, VGA OUT, USB 3.0, USB 2.0, RS232, RJ45, audio.
WiFi + WAN line support, -10℃ to 50℃ operating temperature, MTBF ≥ 50,000 hours. Request Datasheet (PDF)

Key Specifications

Category	Specification
Display	15″ LED-backlit, 1024×768 @50/60Hz, 500 cd/m², H/V ±89° viewing angle
Touch	Projected capacitive (PCAP), 10-point touch, 20/10 ms response time
Front Protection	3mm tempered glass, IP65 front surface
Enclosure	Aluminium housing, IP40 back case
CPU	Intel i3-3217U, dual-core, 1.8GHz
Memory	4GB Kingston DDR3 1600 RAM
Storage	128GB mSATA SSD
Connectivity	WiFi & WAN line
I/O Ports	HDMI OUT, VGA OUT, USB 3.0, USB 2.0, RS232, RJ45, audio
Operating Temp	-10℃ to 50℃
Storage Temp	-20℃ to 70℃
Humidity	Operating: 20–80%; Storage: 5–95%
Mounting	VESA 75×75mm and 100×100mm
Certifications	UL, FCC, CE, CCC
MTBF	≥ 50,000 hours

Talk to an Engineer!

Overview

The 15 inch industrial panel PC delivers rugged performance for demanding HMI, automation, and kiosk applications. Featuring IP65 front protection, Intel i3-3217U processing, 1024×768 high-brightness display (500 cd/m²), and 10-point capacitive touch, this fanless embedded PC withstands harsh environments from -10°C to 50°C.

With rich I/O ports including HDMI, VGA, USB 3.0, RS232, and RJ45, it integrates seamlessly into factory control panels, medical interfaces, and self-service kiosks. VESA 75×75/100×100 mounting ensures flexible panel or cabinet installation while maintaining 50,000+ hour MTBF reliability.

Features & Benefits

IP65 Front with 3mm Tempered Glass

Protection: Dust-tight and water-jet resistant front panel survives washdowns and factory spills.
Benefit: Zero downtime in food processing, pharmaceuticals, or chemical plants requiring frequent cleaning.

500 cd/m² 1024×768 LED Display

Feature: High brightness and ±89° wide viewing angles.
Benefit: Crystal-clear visibility under direct lighting for machine operators and control room supervisors.

10-Point Projected Capacitive Touch

Feature: 20/10ms response time, glove-compatible.
Benefit: Fast, accurate inputs even with work gloves, improving operator efficiency in manufacturing lines.

Intel i3-3217U + 4GB RAM/128GB SSD

Performance: Dual-core 1.8GHz processor with solid-state storage.
Benefit: Handles SCADA visualisation, data logging, and multi-app industrial software without lag.

Fanless Aluminium Housing

Design: Passive cooling eliminates moving parts.
Benefit: Silent 24/7 operation with no dust-clogged fans—perfect for cleanrooms and dusty factories.

Comprehensive Industrial I/O

Ports: HDMI/VGA out, USB 3.0/2.0, RS232, RJ45, WiFi, audio.
Benefit: Direct PLC connectivity, legacy device support, and network redundancy for mission-critical systems.

Wide Temperature Range (-10°C to 50°C)

Environment: Operates in extreme industrial conditions.
Benefit: Reliable performance in cold storage, hot machine rooms, or outdoor kiosks without AC needed.

VESA Mounting Flexibility

Options: 75×75mm and 100×100mm standards.
Benefit: Easy embedded installation into OEM machinery, control cabinets, or kiosk enclosures.

Applications:

This panel PC is perfect for:

Industrial automation systems
Retail kiosks and information displays
Medical equipment interfaces
Interactive digital signage

FAQ

1. Can this 15 inch industrial panel PC operate 24/7 in harsh environments?

Yes. The fanless design with 50,000+ hour MTBF and IP65 front protection ensures reliable 24/7 operation in factories, cleanrooms, and kiosks from -10°C to 50°C.

2. Does it support custom CPU, RAM, or storage configurations?

Absolutely. Standard is Intel i3-3217U, 4GB DDR3, 128GB SSD, but we offer upgrades to i5/i7 processors, 8GB+ RAM, and larger SSD/HDD options for OEM projects.

3. What mounting options are available?

VESA 75×75mm and 100×100mm standard holes for panel mount, embedded installation, or cabinet integration. Custom brackets available upon request.

4. Is the touch screen glove-compatible and responsive?

Yes. 10-point projected capacitive touch with 20/10ms response supports thin gloves and multi-finger gestures for industrial operator efficiency.

5. What is the typical lead time and minimum order quantity (MOQ)?

Samples ship in 7-10 days; bulk orders (MOQ 10 units) in 15-25 days. Rush production available for urgent projects.

6. Does it support legacy industrial interfaces like RS232?

Yes. Includes RS232 serial port, HDMI/VGA video outputs, USB 3.0/2.0, RJ45 Ethernet, and WiFi for full compatibility with PLCs, legacy equipment, and modern networks.

7. What certifications does it have for industrial use?

UL, FCC, CE, CCC, and RoHS compliant. IP65 front panel meets NEMA 4X dust/water standards.
