With a 2,500cd/m2 outward-facing screen to combat direct sunlight, these displays are designed for shopfront windows. On top of this, they are also ultra-resistant to blackening defects up to 70°C with intelligent quiet operation cooling fans.
With a brightness control module, these displays ensure a long and reliable life. They automatically adjust the brightness of the LCD screen according to the brightness of the ambient light, which can save energy to the greatest extent.
With a high MTBF (Mean Time Between Failures) of ≥50,000 hours, these displays offer long-lasting and reliable performance, suitable for continuous operation.
Obtained regulatory approvals and declarations including UL, FCC (US), CE (Europe), and CCC (China), ensuring compliance with industry standards.
The integrated Android media player allows you to update when using our user-friendly online CMS software efficiently, you can upgrade and capitalise on the duality of these displays by broadcasting different your screen to be networked tailor your messaging to people outside the building for maximum effectiveness. Third-party software can be installed instead if required.
Thanks to their streamlined design, these innovative displays feature a 9.5mm slim bezel, to get the biggest active area.
They captivate customers with their vivid image quality and quiet operation. To ensure they can help businesses enhance their brand image while enriching the customers’ shopping experience.
For projects where hanging installation displays is not possible, these versatile displays can also be transformed into a freestanding solution using the optional floor stand. No matter which mounting option you go for, an easy install is guaranteed. Plus, it can be landscape or portrait via VESAs.
| Model Number | SH3203ADO | SH4303ADO | SH4903OADO | SH5503ADO | SH6503ADO | SH7503ADO | SH8603ADO |
| Enclosure Color | Black | ||||||
| Material | Cold-rolled plate material | ||||||
| Touch Technology | N/A | ||||||
| Diagonal Size | 32″ | 43″ | 49″ | 55″ | 65″ | 75″ | 86″ |
| Panel Type | LED-backlit display with IPS technology | ||||||
| Active Area(H*V) | 397.3*702.8mm | 533.8*945.8mm | 608.8*1078.8mm | 684.4*1213.8mm | 807.8*1432.8mm | 934*1655mm | 1071*1900mm |
| Aspect Ratio | 16:09 | ||||||
| Resolution | 1920*1080 | 3840*2160 | |||||
| Brightness | 2500 – 5000 cd/m² | ||||||
| Viewing Angle | Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total | ||||||
| MTBF | ≥50000 hours | ||||||
| Number of Colors | 16.7M | ||||||
| Power Supply | AC100-240V/60HZ | ||||||
| Power Consumption | ＜130W＜145W＜170W＜240W＜460W＜560W＜960W | ||||||
| Standby Power Consumption | ＜10W | ||||||
| Processor | RK3288 Quad-core Cortex-A17 1.8GHz | ||||||
| Rockchip RK3568 (option 1) Quad-core Cortex-A55, 2.0GHz | |||||||
| Ram | 2G | ||||||
| Storage | 8G | ||||||
| OS | Android 5.1+ | ||||||
| Network | WIFI/WAN LINE（3G/4G optional） | ||||||
| Interfaces | HDMI*1; USB*2;RJ45*1;SD*1;Earphone *1 | ||||||
| Video format | MPEG1（VCD）、MPEG2（DVD）、MPEG4、AVI、VOB | ||||||
| Audio format | MP3/WMA/AAC etc. | ||||||
| Image format | jpg,bmp,png,gif | ||||||
| Speakers | 8Ω5W*2 | ||||||
| Brightness control | Built-in light sensor, LCD can be automatically adjusted according to the intensity of the outdoor light | ||||||
| Temperature control | Intelligent temperature regulation cooling system | ||||||
| Timer | Can be timed by day, week or month | ||||||
| Dimensions(mm) | 416.3*721.8*57.2 | 552.8*964.8*57.2 | 627.8*1097.8*57.2 | 703.8*1232.8*57.2 | 826.8*1451.8*57.2 | 953*1674*57.2 | 1097*1926*63.2 |
| Operating Temperature | -10°C to 50°C | ||||||
| Humidity | Operating: 20% to 80%, Storage: 5% to 95% | ||||||
| Mounting Options(VESA) | 400*250mm | 400*400mm | 400*400mm | 400*400mm | 600*400mm | 600*400mm | 600*600mm |
| Regulatory approvals and declarations | UL, FCC (US) , CE (Europe) ,CCC(China) | ||||||
| In the Box | SHXX03 Series, Power Cable, Wall Mounted Bracket, Screws | ||||||
